Block Block
name in
the project
I/O Meaning Value
PV_WL_Lim Low warning limit = 7 m
3
27
SimPV Simulated process value 300
3. Once you have entered the parameters for all the I/Os relating to a block, click "OK" for that
block.
Your settings are applied.
4. Close the CFC.
Note
Assign parameters for the "Mode" I/O for the "Pcs7AnIn" block. You can assign this
parameter only because you have not configured any external I/O modules in this Getting
Started.
6.6.13 Assigning Parameters for blocks in the "CFC_NP111"
Introduction
You have already inserted the "CFC_NP111" CFC as a process tag type. For this chart, you
still need to adapt the default parameter values to your "color_gs" project.
Note
When using process tag types, do not adapt the names of the individual blocks.
Prerequisites
The "CFC_NP111" CFC is open in the CFC Editor - Save in "color_gs_prj_MP\color_gs_prj_Prj
\Plant1\RMT1\ NP111" folder.
Creating CFCs
6.6 Working with the CFC Editor
