Parameters for the "CLOSE_LINE" step in the "Initialization" tab

The following table shows the parameters for the "CLOSE_LINE" step:

No. Column 1 Column 2 Meaning

1 NK111\CFC_NK111\Valve.OpenAut.Value FALSE Close valve

2 NK112\CFC_NK112\Valve.OpenAut.Value FALSE Close valve

3 NK113\CFC_NK113\Valve.OpenAut.Value FALSE Close valve

4 NK114\CFC_NK114\Valve.OpenAut.Value FALSE Close valve

5 FC111\CFC_FC111\DOSE.StartAut.Value FALSE Switch off dosing

6 NP111\CFC_NP111\Motor.StartAut.Value FALSE Switch off motor

7 LI111\CFC_LI111\INT_P.Hold.Value TRUE Stop integrator

8 FC111\CFC_FC111\DOSE.AutModLi.Value FALSE Dosing: Automatic off

9 FC111\CFC_FC111\DOSE.ModLiOp.Value FALSE Dosing in manual mode

10 FC111\CFC_FC111\CTRL_PID.ManModLi.Value TRUE Controller in manual mode

11 FC111\CFC_FC111\CTRL_PID.MV_TrkOn.Value TRUE Manipulated value tracking

Parameters for the step "END" in the "Initialization" tab

The following table shows the parameters for the "END" step:

No. Column 1 Column 2 Meaning

1 NK111\CFC_NK111\Valve.OpenAut.Value FALSE Close valve

2 NK112\CFC_NK112\Valve.OpenAut.Value FALSE Close valve

3 NK113\CFC_NK113\Valve.OpenAut.Value FALSE Close valve

4 NK114\CFC_NK114\Valve.OpenAut.Value FALSE Close valve

5 NP111\CFC_NP111\Motor.AutModOp FALSE Switch off motor

6 FC111\CFC_FC111\CTRL_PID.AutModLi.Value FALSE Controller in manual mode

7 FC111\CFC_FC111\CTRL_PID.ModLiOp.Value FALSE Controller in manual mode

8 FC111\CFC_FC111\CTRL_PID.ManModLi.Value FALSE Controller in manual mode

9 FC111\\CFC_FC111\CTRL_PID.Man 0.0 Manual specification for the

manipulated variable

7.3.3 Assigning parameters to the transitions of the SFC chart

Introduction

A transition contains the conditions according to which a sequential control system passes

control from one step to the next. In principle, you assign parameters for the transitions in the

same way as for the steps.

Creating SFCs

7.3 Setting parameters

PCS 7 SMART Getting Started - Part 1 (V9.0 with APL)

124 Getting Started, 12/2017, A5E42181435-AA
