Siemens simovert masterdrives Compendium

Complex blocks
- Axial winder 784a, 784b
- Software counter 785
- Simple ramp-function generator 1 (32 bit) 786a
- Simple ramp-function generator 2 (32 bit) 786b
- 32-bit gear 1 786c
- 32-bit gear 2 786d
- Shift register 1 787a
- Shift register 2 787b
- Basic positioner
Embedding in basic unit 788
Overview 788a
General notes 788b
Setpoint transfer and mode management 789a
Setup/Positioning 789b
Correction value / homing 789c
- Comfort ramp-function generator 790
- Simple ramp-function generator/ Virtual Master 791
- Technology controller 792
- Setpoint Supply SIMOLINK Encoder SLE 793
- Additive relative/absolute offset angle setting 794
- Offset adder with limitation to ACL 794a
- Extrapolator/Interpolator 794b
- Wobble generator 795
- PRBS (Pseudo Random Binary Sequence) -
Signal mit trace 796
- Trace 797
- Connector-to-parameter converter 798
Function diagram
87654321
fp_mc_701_e.vsd
List of contents
MASTERDRIVES MC
03.03.08
Free blocks
-701 -
V2.5
MASTERDRIVES MC function diagram - List of contents of the free blocks
Contents Sheet
Free blocks: List of contents 701
Setting and monitoring the sampling times and
sampling sequence 702
General function blocks
- Fixed setpoints 705
Fixed control bits 705
Connector/binector displays 705
- Fault/alarm trigger signals 710
- Voltage monitoring of electronics power supply 710
Connector/double-connector converter 710
Double-connector/connector converter 710
- Connector/binector converters 715
- Binector/connector converters 720
Numeric function blocks and control blocks
- Adders 725
Subtracters 725
Sign inverters 725
- Multipliers 730
Dividers 730
- Multipliers/dividers 732
P-amplifiers 732
Shift multipliers/dividers 732
- Delay elements for analog signals 734
Integrators 734
Settable smoothing elements (high resolution) 734
Differentiators (2 word) 734
- Absolute-value generators with smoothing 735
Limiters 735
- Limit-value monitors with and without smoothing 740
- Cam-contactor groups 745, 745a
- Analog-signal switches 750
Analog signal multiplexers and demultiplexers 750
Analog signal muliplexers 753
- Characteristic blocks 755
Dead zone 755
- Selection of minimum/maximum 760
Tracking/storage elements 760
Analog signal storages 760
Logic components
- AND elements 765
OR elements 765
- Inverters 770
NAND elements 770
Exclusive OR elements 770
Digital signal changeover switches 770
- D flipflops 775
RS flipflops 775
- Timers 780
- Pulse generator 782
Sampling time changer 782
Sample & Hold 783
Contents Sheet Contents Sheet
