Siemens simovert masterdrives Compendium

03.2010 Parameterization
Siemens AG 6SE7087-6QX70 (Version AL)
SIMOVERT MASTERDRIVES Compendium Motion Control 5-23
5.4.3.8 Menu selection
The actual parameterization and start-up of the connected slave is
performed by means of the "Menu selection" function. Starting from the
basic menu, the "Menu selection" function is selected with "Lower" or
"Raise". By pressing "P", the unit-specific sub-menu is displayed with
the following choices:
♦ User Param.
♦ Param Menu..
♦ FixedSet...
♦ Quick Param...
♦ Board Conf.
♦ Drive Set
♦ Download
♦ UpR/fr.Access
♦ Power Def.
Two or more dots after these items mean that there is a further sub-
menu level. If "Parameter menu.." is selected, access is possible to all
parameters via correspondingly structured sub-menus. If "UpR/fr.
Access" is selected, direct access is gained to the parameter level.
Menüauswahl
*User Param.
Param Menu..
FixedSet...
P
 
MotionControl
*Menu selection
Upread
Download
r001 9
Drive Status
Ready
Menu selection
Drive Set.
Download
#UpR/fr.Access
7 x
P
 
∇
 
Example: Selecting the parameter level by means of UpR/fr.access
Parameter Menu
*Gen. Param.
Terminals
Communication
P
 
Menu selection
*User Param.
#Param Menu..
FixedSet...
Communication
*SST1/SST2
Field bus conn.
SIMOLINK
Param Menu
*Gen. Param.
Terminals
#Communication
2 x
P
 
∇
 
P700.001
0
SCom Bus Addrese
Ser. Interf.1
P
 
Example: Selecting a parameter via sub-menus
