Parameterization 03.2010
6SE7087-6QX70 (Version AL) Siemens AG
5-20 Compendium Motion Control SIMOVERT MASTERDRIVES
5.4.3.5 OP: Upread
With the "OP: Upread" function, the para
meters of the connected slave
can be upread and stored in the flash memory inside the OP1S.
Starting from the basic menu, the "OP: Upread" function is selected
with "Lower" or "Raise" and started with "P". If the available memory is
insufficient, the procedure is interrupted with an appropriate error
message. During upread, the OP1S indicates the parameter currently
being read. In addition, the slave number is shown at the top on the
right-hand side.
MotionControl 00
Upread
Pxxx
P
MotionControl
*Menu selection
#OP: Upread
OP: Download
Example: Selecting and starting the "Upread" procedure
With "Reset", the procedure can be interrupted at any time. If the
upread procedure has been completed in full, the user is requested to
enter an ID with a maximum of 12 characters for the stored parameter
set. This identification can, for example, consist of the date and two
differentiating numbers. It is entered with the numerical keypad. With
"Lower" a number which has been entered can be deleted.
MotionControl 00
Upread
Enter ID
1-
1
MotionControl 00
Upread
Enter ID
-
MotionControl 00
Upread
Enter ID
190-
MotionControl 00
Upread
Enter ID
19-
and so on
0
9
MotionControl 00
Upread
Enter ID
1909-
9
MotionControl 00
Upread
Enter ID
19091-
1
Example of entering an ID
When "P" is pressed, the message "Upread ok" appears and the
display changes to the basic menu.
