8.2.11 Appendix
Order number
CBP: 6SE7090-0XX84-0FF0
CBP2: 6SE7090-0XX84-0FF5
Size (length x width) 90 mm x 83 mm
Degree of pollution
Degree of pollution 2 acc. to IEC 664-1 (DIN VDE 0110/T1),
Moisture condensation during operation is not permissible
Mechanical strength
In stationary use
• displacement
• acceleration
During transport
• displacement
• acceleration
To DIN IEC 68-2-6 (if board is correctly mounted)
0.15 mm in the frequency range 10 Hz to 58 Hz
19.6 m/s
2
in the frequency range > 58 Hz to 500 Hz
3.5 mm in the frequency range 5 Hz to 9 Hz
9.8 m/s
2
in the frequency range > 9 Hz to 500 Hz
Climatic class Class 3K3 to DIN IEC 721-3-3 (during operation)
Method of cooling Natural air cooling
Permissible ambient or coolant
temperature
• during operation
• during storage
• during transport
0° C to +70° C (32° F to 158° F)
-25° C to +70° C (-13° F to 158° F)
-25° C to +70° C (-13° F to 158° F)
Permissible moisture stress
Relative humidity ≤ 95 % during transport and storage
≤ 85 % during operation (condensation not
permissible)
Supply voltage 5 V ± 5 %, max. 600 mA, internally from the basic unit
Output voltage
5 V ± 10 %, max. 100 mA,
electrically isolated supply (X448/Pin 6)
• for bus termination of the serial interface or
• for supplying an OLP (Optical Link Plug)
Data transfer rate max. 12 MBaud
Table 8.2-33 Technical data
