03.2010 Communication / CBC
Siemens AG 6SE7087-6QX70 (Version AL)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.4-57
8.4.6.4 Meaning of CBC diagnosis
Fault detection configuration
If an invalid value or an invalid combination of parameter values is
contained in the CB parameters, the converter switches to fault mode
with fault F080 and fault value 5 (r949). The cause of the incorrect
parameterization can then be determined by means of this index of CB
diagnostic parameter r731.
Value
(hex)
Meaning
00 No fault/error
01 Incorrect bus address (P918)
02 Incorrect CAN ID in the case of a PKW task (P711 / P696)
03 Internal
04 Internal
05 Incorrect CAN ID in the case of a PKW-task broadcast (P719 / P704)
06 Internal
07 Incorrect CAN ID in the case of a PZD-receive (P712 / P697)
08 -0C Internal
0D Incorrect CAN ID in the case of a PZD-send (P713 / P698)
0E PZD-send length is 0 (P714 / P699)
0F PZD-send length to great (>16) (P714 / P699)
10 - 13 Internal
14 Incorrect CAN ID in the case of a PZD-receive broadcast (P716 / P701)
15 Incorrect CAN ID in the case of a PZD-receive multicast (P717 / P702)
16 Incorrect CAN ID in the case of a PZD-receive cross (P718 / P703)
17 Invalid baud rate (P720 / P705)
18 - 22 Internal
23 Incorrect CAN protocol type (P721 / P706.01)
24
PKW-request broadcast (P719 / P704)
without PKW task (P711 / P696)
25 .. 2F Reserved
30 Overlapping of CAN identifier PKW <-> PKW-broadcast
31 Overlapping of CAN identifier PKW <-> PZD-receive
32 Overlapping of CAN identifier PKW <-> PZD-send
33 Overlapping of CAN identifier PKW <-> PZD-receive broadcast
34 Overlapping of CAN identifier PKW <-> PZD-receive multicast
35 Overlapping of CAN identifier PKW <-> PZD-receive cross
36 Overlapping of CAN identifier PKW-broadcast <-> PZD-receive
37 Overlapping of CAN identifier PKW-broadcast <-> PZD-send
38
Overlapping of CAN identifier PKW-broadcast <-> PZD-receive
broadcast
P732.1
