Communication / CBC 03.2010
6SE7087-6QX70 (Version AL) Siemens AG
8.4-60 Compendium Motion Control SIMOVERT MASTERDRIVES
8.4.7 Appendix
Order No. 6SE7090-0XX84-0FG0
Size (length x width) 90 mm x 83 mm
Degree of pollution
Pollution degree 2 to IEC 664-1 (DIN VDE 0110/T1),
Moisture condensation during operation is not permissible
Mechanical specifications
During stationary use
• deflection
• acceleration
During transport
• deflection
• acceleration
To DIN IEC 68-2-6 (if board correctly mounted)
0.15 mm in the frequency range 10 Hz to 58 Hz
19.6 m/s
2
in the frequency range > 58 Hz to 500 Hz
3.5 mm in the frequency range 5 Hz to 9 Hz
9.8 m/s
2
in the frequency range > 9 Hz to 500 Hz
Climatic class Class 3K3 to DIN IEC 721-3-3 (during operation)
Type of cooling Natural-air cooling
Permissible ambient or cooling-
medium temperature
• during operation
• during storage
• during transport
0° C to +70° C (32° F to 158° F)
-25° C to +70° C (-13° F to 158° F)
-25° C to +70° C (-13° F to 158° F)
Humidity rating
Relative humidity
≤ 95 % during transport and storage
≤ 85 % during operation (moisture condensation
not permissible)
Supply voltage 5 V ± 5 %, max. 500 mA, internally from the basic unit
Technical data
