08.2012 Technology Option F01
Siemens AG 6SE7087-6QX70 (Version AN)
SIMOVERT MASTERDRIVES Compendium Motion Control 9-123
9.7 Application examples
9.7.1 Positioning of a linear axis via PROFIBUS
Application examples can be requested from the regional office of
SIEMENS AG or from the application center for production machines.
9.7.2 Positioning and synchronization with virtual master axis
(suitable for self-study)
9.7.2.1 Task description
This example is intended to
♦ Help the user configure and commission the drive
♦ Provide a rapid means of familiarization with the positioning and
synchronization functions with reference to a trial configuration.
You can run this example application using the 2-axis demonstration
pack available from Siemens (Order No. 6SX7000-0AF10; see /1/).
You need the following components in order to use the example
configuration:
Component Quantity Required
for Positioning
Quantity Required
for
Synchronization
1FT6 or 1FK6 motor with resolver
or encoder *)
1 2
MASTERDRIVES MC with option
F01 and the matching sensor
board
1 2
Switch box with 6 switches 1 2
Potentiometer, approx. 10 K **) --- 1
OR
1-axis demo. pack /5/ 1 2
OR
2-axis demo. pack /6/ 1 1
*) An asynchronous motor can also be used, however some parameter settings require
slight modification.
**) You can connect the +10 V terminal on the potentiometer to the analog output on
terminal X101.11. You must then set P640 = 1 [80.1], so that +10 V is output at the
analog output (corresponds to 100 %).
