Communication / CBC CANopen Communication Board 02.2004
6SE7087-6QX70 (Version AD) Siemens AG
8.5-56 Compendium Motion Control SIMOVERT MASTERDRIVES
8.5.4.2 Error codes
Undecoded errors are assigned error code 1000 hex. Read the error
number from byte 4.
Undecoded alarms are assigned error code 1001 hex. Read the alarm
number from byte 3.
The CB errors and alarms can be found in Subsection 8.5.8.
Error code
(hex)
Meaning MC error MC alarm Error text /
description
2300 current on device output side F021 Motor I
2
t
2310 continuous over current F011 Overcurrent
2331 earth leakage phase U F025 UCE top switch/UCE phase L1
2332 earth leakage phase V F026
UCE bottom switch/UCE phase
L2
2333 earth leakage phase W F027
Pulse resistor fault/UCE phase
L3
2380 I2t Converter A025 I2t converter
2381 I2t motor A029 I2t motor
3210 DC link over-voltage F006 DC link overvoltage
3220 DC link under-voltage F008 DC link undervoltage
3230 load error F002 Fault/precharge
4210 Excess temperature device F023 Inverter overtemperature
4280 Inverter temperature A022 Inverter temperature
4310 Excess temperature drive F020 Motor overtemperature
4380 Motor temperature A023 Motor temperature
5112 U2=supply +24V F017 SAFE STOP
5114 SAVE OFF alarm active A017 SAFE STOP alarm active
5530 EEPROM F041 EEPROM error
5580 Fault in EEPROM F255 Error in EEPROM
6100 internal software F040 Internal error sequence control
6180 Time slot overflow F042 Time slot overflow
6181 DSP link F043 DSP coupling
6182 BICO Manager fault F044 BICO manager error
6183 Time slot overflow A001 Time slot overflow
6310 loss of parameters F038
Voltage OFF during parameter
save
Error code 1000 hex
Error code 1001 hex
Table of error codes
