Siemens simovert masterdrives

Function diagram
87654321
fp_mc_799_e.vsd
Technology option
MASTERDRIVES MC
14.10.10
Cover sheet
-799 -
Notes: - The F01 technology option must have been enabled:
PIN- Nr.
The F01 technology option can only be used with MASTERDRIVES units which are
supplied ex-works with the enabled F01 option or for which this option has been enabled
retrospectively by means of the PIN No.
The display parameter n978 can be used to check if the F01 option is present:
n978.1 = 2 ==> F01 technology option has been enabled for 500 hours
n978.1 = 1 ==> F01 technology option has been enabled
n978.1 = 0 ==> F01 has been disabled
On sheet [850], you can find out how you can retrospectively enable the technology option
on a permanent basis or for a 500-hours trial period.
- The technology functions are performed only if they are specifically nested in a sampling time by means of the
assigned U95x parameter; see also sheets [702] and [802]! If the F01 technology option has not been enabled,
when an attempt is made to nest a technology function in a sampling time, error message F063 appears.
- MD1 ... MD50 = Machine data for positioning (stored in parameters U501.01 ... U501.50); see [804]
-LU = L
ength Unit = The unit of length defined by the position-feedback scaling factor (PSF). The PSF is
specified by means of P169/P170 [330] if the motor encoder is used and by means of P155/P156
[335] if an external machine encoder is used.
PIN-No.
- The following technology function can also be used without enabling of the technology option:
- 833 - Real master with dead time compensation
V2.5
- The technology functions synchronization (U953.33) and positioning (U953.32) must not be enabled at the same time.
