Siemens simovert masterdrives Compendium

08.2012 Technology Option F01
Siemens AG 6SE7087-6QX70 (Version AN)
SIMOVERT MASTERDRIVES Compendium Motion Control 9-153
9.8.3 Checking the speed/position controller
Commissioning step:
Check the speed/position controller:
If you are in any doubt as to whether the correct speed/position
controller, the correct encoder cable or the correct sensor board are
mounted, you should carry out the following checks:
Checking the encoder:
♦ For 1FK6 and 1FT6 motors, optical sin/cos encoder ERN1387/1381
is identified by the appearance of "Optical Encoder" on the
nameplate.
♦ For 1FK6 and 1FT6 motors, multiturn absolute encoder EQN1325 is
identified by the appearance of "Absolute Encoder" on the
nameplate.
♦ For 1FK6 and 1FT6 motors, the resolver is identified by the
appearance of "Resolver" on the nameplate or by the absence of an
encoder type designation on the nameplate.
Checking the encoder cable for 1FK6, 1FT6 and 1PA6 motors:
♦ The correct encoder cable for the
resolver can be identified from
the order number "6FX
002-2CF01-0", which is printed in
red on the cable (
 = option and length specification).
♦ The correct encoder cable for the
ERN1387/1381 can be identified
from the order number "6FX
002-2CA31-0", which is
printed in red on the cable (
 = option and length specification).
♦ The correct encoder cable for multiturn absolute encoder
EQN1325
can be identified from the order number
"6FX
002-2EQ00-0", which is printed in red on the cable
(
 = option and length specification).
♦ The correct encoder cable for the
pulse encoder (with unipolar HTL
signals) can be identified from the order number
"6SX7002-0
H00-0", which is printed in red on the cable
(
 = option and length specification).
The connector and terminal assignments on the motor and sensor
boards are described in Catalog DA65.11.
