12.2010 Configuration and Connection Examples
Siemens AG 6SE7087-6QX70 (Version AM)
SIMOVERT MASTERDRIVES Compendium Motion Control 2-23
2.4.4 Safety functions
The following safe stop functions can be implemented with the
SIMOVERT MASTERDRIVES converter system by means of
appropriate circuitry:
Designation
according to
IEC61800-5-2
Former
designation
Former
description
Safe Torque Off
Safe Torque Off
STO
SH Safe standstill
Safe Stop 1
Safe Stop 1
(time controlled)
SS1
Ext. STOP B
Stop Category 1
Quick stop
It should be noted that the safety functions represent only a very small
minority of the device functions.
Through selection of appropriate circuitry, it is possible to build a two-
channel structure with appropriate fault detection mechanisms for
safety functions.
The line contactor and the line fuses in the feeder cable must be
designed and dimensioned in accordance with the specifications given
in catalogs DA 65.10 and DA 65.11 or the Engineering Information. The
main switch –Q0 serves as a line disconnection device in accordance
with EN 60204-1:2006 /R9/ and is disregarded in the context of
functional safety.
