Siemens simovert masterdrives Compendium

03.2010 Parameterization
Siemens AG 6SE7087-6QX70 (Version AL)
SIMOVERT MASTERDRIVES Compendium Motion Control 5-29
5.4.3.9 Issuing commands via the OP1S
Control functions and setpoint specifications for the connected unit can
be selected with the corresponding keys of the OP1S, for example
during start-up. To do so, the sources of the control commands have to
be added to the corresponding bits of word 1 of the SCom1 interface.
For setpoint specification, the sources of the setpoints must be
appropriately "interconnected". In addition, the setpoint to be changed
is to be parameterized as a displayed value in the 3rd line of the
operating display.
Key Function Parameter number Parameter value
O
ON/OFF1
P554
Source ON/OFF1
2100
Motorized potentiometer: setpoint
higher, lower (only effective within
the operating display)
P573
Source Raise MOP
P574
Source Lower MOP
P443
Source Main Setpoint
P049.004
Setpoint Operating Disp
2113
2114
KK0058
(MOP Output)
424
(MOP Out)
0
to
9
or
Setpoint specification by means
of fixed setpoint (only effective
within the operating display. If
entered with numerical key,
confirm with "P")
P443
Source Main Setpoint
P573
Source Raise MOP
P574
Source Lower MOP
P049.004
Setpoint Operating Disp
KK0040
(Fixed setpoints)
0
0
e.g. 401
(selected fixed setpoint)
Reversing
P571
Source clockwise direc.
of rotation
P572
Source anti-clockwise
direc. of. rotation
2111
2112
Reset
Acknowledging (only effective
within the operating display)
P565
Source Acknowledge
2107
Jog
Jogging with jog setpoint 1 (only
effective in the "Ready" status)
P568
Source Jog Bit 0
P448
Jog Setpoint 1
2108
Setpoint in %
The OFF function can also be performed with OFF2 or OFF3 instead of
OFF1. For this, the source of OFF2 (P555) or OFF3 (P556) must be
"interconnected" to 2101 or 2102 respectively in addition to setting
P554.
NOTE
