02.2004 Communication / CBC CANopen Communication Board
Siemens AG 6SE7087-6QX70 (Version AD)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.5-103
8.5.8.2 Evaluation of CBC diagnostic parameter
The CBC stores diagnostic data in a diagnostic buffer to support
commissioning and servicing activities. The diagnostic information can
be read out with indexed parameter r732.i (CB/TB diagnosis). This
parameter is displayed in hexadecimal notation.
The CBC diagnostics buffer is assigned as follows:
Meaning
r 732.01 Error identifier configuration (1)
r 732.02 Not used
r 732.03 Not used
r 732.04 Not used
r 732.05 Not used
r 732.06 Not used
r 732.07 Not used
r 732.08 Not used
r 732.09 Not used
r 732.10 Not used
r 732.11 Not used
r 732.12 Not used
r 732.13 Not used
r 732.14 Counter for properly processed PKW tasks (incl. response)
r 732.15 Counter for errors in processing PKW tasks (incl. response)
r 732.16 Error type of error in processing PKW tasks
r 732.17 Error value of error in processing PKW tasks
r 732.18 Not used
r 732.19 Parameter which cannot be read out during initialization. (only MC)
r 732.20 Not used
r 732.21 Not used
r 732.22 Not used
r 732.23 Not used
r 732.24 Not used
r 732.25 Not used
r 732.26 Software version
r 732.27 Software identifier
r 732.28 Software date 'Day/Month'
r 732.29 Software date 'Year'
