Communication / CBC 03.2010
6SE7087-6QX70 (Version AL) Siemens AG
8.4-56 Compendium Motion Control SIMOVERT MASTERDRIVES
8.4.6.3 Evaluation of the CBC diagnostic parameter
NOTE
Please note that, for types of unit with the older function classes FC
(CU1), VC (CU2) and SC (CU3), indexed parameter r731.i is to be
used appropriately instead of r732.i
The CBC stores this information in a diagnostics buffer to support start-
up and for service purposes. The diagnostic information can be read
out with indexed parameter r732.i (CB/TB diagnosis). This parameter is
displayed as a hexadecimal. The CBC diagnostics buffer is assigned as
follows:
Meaning r731.i r732.i
Fault detection configuration r731.1 r732.1
Counter: telegrams received without faults/errors r731.2 r732.2
Counter: lost PZD telegrams r731.3 r732.3
Counter for Bus-Off states r731.4 r732.4
Counter for error-warning states r731.5 r732.5
Assigned internally
r731.6 r732.6
Assigned internally
r731.7 r732.7
Assigned internally
r731.8 r732.8
Assigned internally
r731.9 r732.9
Counter for PZD telegrams sent without errors/faults r731.10 r732.10
Counter for faults during transfer of PZD telegrams r731.11 r732.11
Assigned internally
r731.12 r732.12
Assigned internally
r731.13 r732.13
Counter for PKW tasks processed without errors/faults r731.14 r732.14
Counter for faults/errors during processing of PKW tasks r731.15 r732.15
Type of fault/error in the case of faults during processing
of PKW tasks
r731.16 r732.16
Assigned internally
r731.17 r732.17
Counter for lost PKW tasks r731.18 r732.18
Reserved
r731.19 r732.19
Reserved
r731.20 r732.20
Reserved
r731.21 r732.21
Reserved
r731.22 r732.22
Reserved
r731.23 r732.23
Assigned internally
r731.24 r732.24
Assigned internally
r731.25 r732.25
Software version r731.26 r732.26
Software identification r731.27 r732.27
Software date, day/month r731.28 r732.28
Software date, year r731.29 r732.29
Table 8.4-16 CBC diagnostics buffer
CBC-diagnosis
parameter
