Siemens simovert masterdrives Compendium

12.2010
Siemens AG 6SE7087-6QX70 (Version AM)
SIMOVERT MASTERDRIVES Compendium Motion Control 9
For 1PH7, 1PH4, and 1PL6 motors, the up-to-date calculation data
have been stored in the unit. These might differ from the rating plate
slightly. Always use the data stored. The magnetization current is
determined by automatic parameterization.
1PH7xxx is the new designation of what were formerly 1PA6xxx
motors. The 1PH7xxx and 1PA6xxx data therefore tally.
Input in
P097
Motor order
number
(MPRD)
Rated
speed
n
n
[rpm]
Pole pair
number
Z
p
Current
I
n
[A]
Voltage
U
n
[V]
Torque
M
n
[Nm]
Frequency
f
n
[Hz]
1 1PH7101-2_F 1750 2 9.7 398 23.5 60.0
2 1PH7103-2_D 1150 2 9.7 391 35.7 40.6
3 1PH7103-2_F 1750 2 12.8 398 34.1 61.0
4 1PH7103-2_G 2300 2 16.3 388 31.1 78.8
5 1PH7105-2_F 1750 2 17.2 398 43.7 60.0
6 1PH7107-2_D 1150 2 17.1 360 59.8 40.3
7 1PH7107-2_F 1750 2 21.7 381 54.6 60.3
8 1PH7131-2_F 1750 2 23.7 398 70.9 59.7
9 1PH7133-2_D 1150 2 27.5 381 112.1 39.7
10 1PH7133-2_F 1750 2 33.1 398 95.5 59.7
11 1PH7133-2_G 2300 2 42.4 398 93.4 78.0
12 1PH7135-2_F 1750 2 40.1 398 117.3 59.5
13 1PH7137-2_D 1150 2 40.6 367 161.9 39.6
14 1PH7137-2_F 1750 2 53.1 357 136.4 59.5
15 1PH7137-2_G 2300 2 54.1 398 120.4 77.8
16 1PH7163-2_B 400 2 28.2 274 226.8 14.3
17 1PH7163-2_D 1150 2 52.2 364 207.6 39.2
18 1PH7163-2_F 1750 2 69.1 364 185.5 59.2
19 1PH7163-2_G 2300 2 77.9 374 157.8 77.4
20 1PH7167-2_B 400 2 35.6 294 310.4 14.3
21 1PH7167-2_D 1150 2 66.4 357 257.4 39.1
22 1PH7167-2_F 1750 2 75.3 398 223.7 59.2
23 1PH7184-2_B 400 2 51.0 271 390 14.2
24 1PH7184-2_D 1150 2 89.0 383 366 39.2
25 1PH7184-2_F 1750 2 120.0 388 327 59.0
26 1PH7184-2_L 2900 2 158.0 395 265 97.4
27 1PH7186-2_B 400 2 67.0 268 505 14.0
28 1PH7186-2_D 1150 2 116.0 390 482 39.1
29 1PH7186-2_F 1750 2 169.0 385 465 59.0
Asynchronous
motors
1PH7 / 1PL6 / 1PH4
NOTE
