Siemens simovert masterdrives Compendium

08.2012 Technology Option F01
Siemens AG 6SE7087-6QX70 (Version AN)
SIMOVERT MASTERDRIVES Compendium Motion Control 9-151
9.7.4 Roll feed
(under development)
9.7.5 Application using the SIMATIC S7 GMC software
(under development)
9.8 Commissioning the technology
9.8.1 Measurement and diagnostics resources
Commissioning step:
Familiarize yourself with the measurement and diagnostics
resources:
The following measurement and diagnostics resources are available for
MASTERDRIVES MC:
♦
Faults, warnings, diagnostics:
Read the section of the same name at the end of this chapter of the
Compendium to find out which warnings and faults are generated by
the technology and which technology signals you can track in the
monitoring parameters.
♦
Connector status in display parameters:
You can connect any connector or binector to a display parameter,
in order to track signals during commissioning and troubleshooting.
These freely connectable display parameters are listed on sheets
[30] and [705] of the function diagram.
Example:
U045=803 [705.7] => You can observe the status of binector B803
"engaging/disengaging cycle running" [834.5] in display parameter
n046
♦
Recording signals with the integrated trace function:
A high-speed real-time trace function is available on the
MASTERDRIVES MC for recording any connectors and binectors.
You can operate this function conveniently with DriveMonitor. The
trace function has the following features (see also the online help in
DriveMonitor):
• Flexible setting of time resolution from 500 µs
• 8 measuring channels
• Memory capacity: over 10 000 samples per channel
• Flexible setting of zero offset and gain for the signal display
across large range
• Settable
• Flexible setting of trigger condition (trigger signal, trigger
threshold, post/pre-trigger)
