Communication / CBC CANopen Communication Board 02.2004

6SE7087-6QX70 (Version AD) Siemens AG

8.5-60 Compendium Motion Control SIMOVERT MASTERDRIVES

8.5.6 The state machine

Power

Disabled

Not Ready to

Switch On

Start

Switch On

Disabled

2 7

Ready to

Switch On

Fault

Fault Reaction

Active

Power

Enabled

Switched On

4 5

Operation

Enable

Quick Stop

Activ

121063

Fig. 8.5-3 The state machine

The state machine is similar to that of the MASTERDRIVES. Please

see Chapter 12 "Function Diagrams", diagram 520 for an explanation of

how individual states of the MASTERDRIVES can be reached.

Transition 8 is the only transition which is not available in

MASTERDRIVES.

It has been implemented by skipping the status change from Operation

Enable to Switch On Disabled in transition 9.
