Siemens simovert masterdrives Compendium

Parameterization 03.2010
6SE7087-6QX70 (Version AL) Siemens AG
5-16 Compendium Motion Control SIMOVERT MASTERDRIVES
5.4.3 Operator control
5.4.3.1 Operator control elements
Key Significance Function
ON key
• For energizing the drive (enabling motor activation). The
function must be enabled by P554.
O
OFF key
• For de-energizing the drive by means of OFF1, OFF2 or
OFF3. The function must be enabled by P554 to P560.
Jog
Jog key
• For jogging with jog setpoint 1 (only effective when the
unit is in the "Ready to start" state). This function must
be enabled by P568.
Reversing key
• For reversing the direction of rotation of the drive. This
function must be enabled by P571 and P572.
P
Toggle key
• For selecting menu levels and switching between
parameter number, parameter index and parameter
value in the sequence indicated. The current level is
displayed by the position of the cursor on the LCD
display (the command comes into effect when the key is
released).
• For conducting a numerical input.
Reset
Reset key • For leaving menu levels
• If fault display is active: For acknowledging the fault. This
function must be enabled by P565
Raise key For increasing the displayed value:
• Short press = single-step increase
• Long press = rapid increase
• If motorized potentiometer is active, this is for raising the
setpoint. This function must be enabled by P573
Lower key For lowering the displayed value:
• Short press = single-step decrease
• Long press = rapid decrease
• If motorized potentiometer is active, this is for lowering
the setpoint. This function must be enabled by P574
+/-
Sign key
• For changing the sign so that negative values can be
entered
0
to
9
Number keys • Numerical input
Table 5-9 Operator control elements of the OP1S
