09.2008 Communication / PROFIBUS
Siemens AG 6SE7087-6QX70 (Version AK)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.2-139
Diagnosis of the setpoint source (especially during cross traffic)
P711.x r732.x Content High byte Low byte
31 r732.9 Setpoint 2 Setpoint 1
P732.10 Setpoint 4 Setpoint 3
P732.11 Setpoint 6 Setpoint 5
P732.12 Setpoint 8 Setpoint 7
P732.13 Setpoint 10 Setpoint 9
P732.14 Setpoint 12 Setpoint 11
P732.15 Setpoint 14 Setpoint 13
P732.16
Setpoint source:
0: Master
1 to 8: cross-traffic encoder
9: -
Setpoint 16 Setpoint 15
P732.17 Setpoint 2 Setpoint 1
P732.18 Setpoint 4 Setpoint 3
P732.19 Setpoint 6 Setpoint 5
P732.20 Setpoint 8 Setpoint 7
P732.21 Setpoint 10 Setpoint 9
P732.22 Setpoint 12 Setpoint 11
P732.23 Setpoint 14 Setpoint 13
P732.24
Byte offset of the setpoint within
the setpoint source
(value range 0 to 30)
Setpoint 16 Setpoint 15
Diagnosis of clock synchronization
P711.x r732.x Content
32 r732.9 Interrupt enable by the basic board
r732.10 RCC parameter 1
r732.11 RCC parameter 2
r732.12 Synchronization mode from the basic board
