Function diagram
87654321
fp_mc_Z20_e.vsd
SCB1 with SCI1
MASTERDRIVES MC
08.01.02
SCI1 - analog inputs slave 1
- Z20 -
V2.5
Hardware smoothing
1 ms
A
D
12 bit + sign
Smoothing
.5
.3
.4
U
± 10 V
I
± 20 mA
3
4
4
5
Hardware smoothing
1 ms
A
D
12 bit + sign
Smoothing
.8
.6
.7
Hardware smoothing
1 ms
A
D
12 bit + sign
Smoothing
.11
.9
.10
-X428
<1>
<1>
<1>
<2>
<2>
<2>
.1
.2
+10 V/5 mA for potentiometer,
short-circuit proof
-10 V/5 mA for potentiometer,
short-circuit proof
Value range calculated acc. to following equation:
T = 2 ms 2
P691.x
<1> Value range:
(For further terminals,
see function diagram
"SCI1 - analog outputs slave1")
Terminals Terminals
X428.3, .6, .9 X428.5, .8, .11
0: -10 ... 10 V -20 ... 20 mA
1: 0 ... 10 V 0 ... 20 mA
2: - 4 ... 20 mA
<2> Signal type:
Not with Compact PLUS!
SCI AnaIn Offset
-20.00 ... 20.00 V
P692.1 (0)
K4101 SCI Sl.1 AnaIn
SCI AnaIn Conf
0 ... 2
P690.1 (0)
SCB/SCI Values
r699.2
SCI AnaInSmooth
0 ... 15
P691.1 (2)
SCI AnaIn Offset
-20.00 ... 20.00 V
P692.2 (0)
K4102 SCI Sl.1 AnaIn
SCI AnaIn Conf
0 ... 2
P690.2 (0)
SCB/SCI Values
r699.3
SCI AnaInSmooth
0 ... 15
P691.2 (2)
SCI AnaIn Offset
-20.00 ... 20.00 V
P692.3 (0)
K4103 SCI Sl.1 AnaIn
SCI AnaIn Conf
0 ... 2
P690.3 (0)
SCB/SCI Values
r699.4
SCI AnaInSmooth
0 ... 15
P691.3 (2)
U953.25 = ___(4)
