Siemens simovert masterdrives Compendium

Function diagram
87654321
fp_mc_846_e.vsd
Technology Option
MASTERDRIVES MC
03.11.03
Synchronism status signals
-846 -
V2.5
Synchronism
status word
Display on PMUDisplay on PMU
From synchronism block
BIT7 = Internal process table position < 0
31 30
23 22
29 28
21 20
27 26
19 18
25 24
17 16
BIT6 = Internal process table position > process table width
15 14
76
13 12
54
11 10
32
98
10
BIT15 = Spare
Sync. status word
High-Word
n450.2
Sync. status word
Low-Word
n450.1
B0800 BIT1 = Correction of external synchronization operating
B0803 BIT2 = Start/stop operating
B0832 BIT3 = Start active
B0833 BIT4 = Stop active
B0831 BIT5 = Ramp inactive, Start/stop in constant-speed operation
B0810 BIT8 = Adjustment active
B0811 BIT9 = Synchronous with master setpoint
B0808 BIT10 = Axis referenced
B0809 BIT11 = Axis not referenced
B0820 BIT12 = Catch-up ended
B0821 BIT13 = Catch-up is positioned
B0822 BIT14 = Catch-up setpoint speed reached
B0836Bit16 = CorrValue on synchronization < F1
B0837Bit17 = CorrValue on synchronization < F2
B0812Bit18 = Memory backstop active
B0813Bit19 = Current backstop not active
B0829 BIT0 = Print mark outside window 2
B0801Bit20 = Acceleration ramp active
B0802Bit21 = Deceleration ramp active
B0814Bit22 = Change to Src Variable Ramps permitted
KK0800
Synchronism
status word
B0826Bit23 = Continue synchronism active (FRZ_ON)
B0834
Stop at end of table
