Example:
P554.1 = 10
P554.2 = 2100
A total of 2 values are stored under parameter P554 (Src ON/OFF1). If
BICO data set 1 is active, the ON command comes from digital input 1
of the basic unit. If BICO data set 2 is active, the ON command comes
from bit 0 of the first data word received by serial interface 1.
Individual BICO data sets are selected by means of control word bit 30
in control word 2 (P590.
The active BICO data set is displayed via visualization parameter r012
(Active BICO DS).
All indexed BICO parameters are always switched jointly between
parameter index 1 and 2.
Visualization parameters are used for visualizing internal quantities
(e.g. applicable output current). These parameters are only displayed
and cannot be changed by you.
To distinguish them from the other parameters, they are designated
with a lower-case letter (r, n, d and c) in the parameter number.
r006
DC Bus Volts
Parameter number
Parameter name
Fig. 4-7 Visualization parameters
CAUTION
Visualization
parameters
