Siemens simovert masterdrives

Parameter
Description Data Read/write
U629*
#InterpolPoint
2629
The parameter defines the number of relevant
interpolation points in the table. If more pairs of variables
are defined than the number of interpolation points, these
are ignored.
Changing this parameter sets the status of the associated
table to "untested".
Exception: In the case of configuration 4 and parameter
value = 0, the status of the associated table is set to
"table does not exist"
Function diagram [839.3]
index1: 0
Min: 0
Max: 800
Unit: -
Indices: 8
Type: O2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U630*
Tab X1-X50
2630
This parameter is used to input x-coordinates 1 to 50 of
the table
Function diagram [839.4]
index1: 0
Min: 0
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U631*
Tab X51-X100
2631
This parameter is used to input x-coordinates 51 to 100 of
the table
Function diagram [839.4]
index1: 0
Min: 0
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U632*
Tab X201-X250
2632
This parameter is used to input x-coordinates 201 to 250
of the table
Function diagram [839.4]
index1: 0
Min: 0
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
U633*
Tab X251-X300
2633
This parameter is used to input x-coordinates 251 to 300
of the table
Function diagram [839.4]
index1: 0
Min: 0
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
n634
FreeInterpolPts
2634
This parameter shows the free intermediate points still
available in the variable configuration [(U615 = 0) of the
table
Max. value = 400
Min. value = 0
Dec.Plc.: 0
Unit: -
Indices: -
Type: O2
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
U635*
Tab Y1-Y50
2635
This parameter is used to input y-coordinates 1 to 50 of
the table
Function diagram [839.4]
index1: 0
Min: -
2147483648
Max:
2147483647
Unit: -
Indices: 50
Type: I4
Menus:
- Parameter menu
+ Technology
+ Synchronism
- Upread/free access
Changeable in:
- Ready to switch on
- Operation enabled
207
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
