03.2010
6SE7087-6QX70 (Version AL) Siemens AG
12 Compendium Motion Control SIMOVERT MASTERDRIVES
Number / Fault Cause Counter-measure
F142
Technology board fault
not Compact PLUS
See TB documentation See TB documentation
F143
Technology board fault
not Compact PLUS
See TB documentation See TB documentation
F144
Technology board fault
not Compact PLUS
See TB documentation See TB documentation
F145
Technology board fault
not Compact PLUS
See TB documentation See TB documentation
F146
Technology board fault
not Compact PLUS
See TB documentation See TB documentation
F147
Technology board fault
not Compact PLUS
See TB documentation See TB documentation
F148
Fault 1
Function blocks
An active signal is present at binector U061
(1).
Examine cause of fault, see function diagram
710
F149
Fault 2
Function blocks
An active signal is present at binector U062
(1).
Examine cause of fault, see function diagram
710
F150
Fault 3
Function blocks
An active signal is present at binector U063
(1).
Examine cause of fault, see function diagram
710
F151
Fault 4
Function blocks
An active signal is present at binector U064
(1).
Examine cause of fault, see function diagram
710
F152
Signs of life repeatedly
invalid.
After an appropriate number of invalid signs of
life, the sign of life monitoring block has gone
into fault status.
Check cause of fault, see function diagram
170
F153
No valid sign-of-life tool
interface
Within the monitoring time of the tool interface
no valid sign-of-life has been received from the
tool interface.
Cyclically execute write tasks from the tool
interface within the monitoring time whereby
the sign-of-life has to be increased by 1 for
every write task.
F255
Fault in EEPROM
A fault has occurred in the EEPROM. Switch off the unit and switch it on again. If the
fault re-occurs, replace CU (-A10), or replace
the unit (Compact PLUS).
Table 1 Fault numbers, causes and their counter-measures
