26 Compendium Motion Control SIMOVERT MASTERDRIVES
Number / Alarm Cause Counter-measure
A178
Program number of
block search forward
not allowed
- The program number for the main program
(level 0), which was transferred with block
search, is different from the selected program
number.
- No breakpoint is known for the "automatic
block search" function (a program abort has
not yet occurred).
- A different program number is stored as the
breakpoint for the "automatic block search"
function.
Effect:
NC program execution is inhibited.
For the block search function, the selected
program number [PROG_NO] must be
specified as the program number for the main
program.
A179
Prog.No.of block srch
fwd level 1/2 does not
exist
The subprogram number specified with block
search for level 1 or level 2 does not exist.
Effect:
NC program execution is inhibited.
For the block search function, an existing
program number must be specified as the
subprogram number for level 1 or level 2.
A180
Prog.no. of block
search forward level 1
<> cmd.
The subprogram number transferred with
block search for level 1 is not the same as the
subprogram number in the NC block.
Effect:
NC program execution is inhibited.
For the block search function, the subprogram
number specified in the NC block must be
specified as the subprogram number for level
1.
A181
Prog.no. of block
search forward level 2
<> cmd.
The subprogram number transferred with
block search for level 2 is not the same as the
subprogram number in the NC block.
Effect:
NC program execution is inhibited.
For the block search function, the subprogram
number specified in the NC block must be
specified as the subprogram number for level
2.
A183
Block no. of block
search fwd l. 0 does
not exist
The block number for the main program (level
0), which was transferred with block search,
does not exist in the main program.
Effect:
NC program execution is inhibited.
For the block search function, an existing
block number must be specified as the block
number for the main program.
A184
Block no. of block
search forward is no
UP call
The block number for the main program (level
0), which was transferred with block search,
does not contain a subprogram call for
subprogram level 1.
Effect:
NC program execution is inhibited.
For the block search function, a block number
with a subprogram call must be specified as
the block number for the main program (level
0) if a block search is to be performed in
subprogram level 1.
A185
Block no. of block
search forward does
not exist
The block number for subprogram level 1,
which was transferred with block search, does
not exist in the subprogram.
Effect:
NC program execution is inhibited.
For the block search function, a block number
which exists in this subprogram must be
specified as the block number for subprogram
level 1.
A186
Block no of block
search fwd lev 1 is no
SP call
The block number for subprogram level 1,
which was transferred with block search, does
not contain a subprogram call for subprogram
level 2.
Effect:
NC program execution is inhibited.
For the block search function, a block number
with a subprogram call must be specified as
the block number for subprogram level 1 if a
block search is to be performed in subprogram
level 2.
A187
Block no of block
search fwd lev 2 does
not exist
The block number for subprogram level 2,
which was transferred with block search, does
not exist in the subprogram.
Effect:
NC program execution is inhibited.
For the block search function, a block number
which exists in this subprogram must be
specified as the block number for subprogram
level 2.
