08.2012 Parameterizing Steps

Siemens AG 6SE7087-6QX70 (Version AN)

SIMOVERT MASTERDRIVES Compendium Motion Control 6-7

Order number In [A] P070

6SE7011-5EP0 1.5 1

6SE7013-0EP0 3.0 3

6SE7015-0EP0 5.0 5

6SE7018-0EP0 8.0 7

6SE7021-0EP0 10.0 9

6SE7021-4EP0 14.0 13

6SE7022-1EP0 20.5 15

6SE7022-7EP0 27.0 17

6SE7023-4EP0 34.0 19

Order number In [A] P070

6SE7012-0TP0 2.0 2

6SE7014-0TP0 4.0 4

6SE7016-0TP0 6.1 6

6SE7021-0TP0 10.2 8

6SE7021-3TP0 13.2 12

6SE7021-8TP0 17.5 14

6SE7022-6TP0 25.5 16

6SE7023-4TP0 34.0 18

6SE7023-8TP0 37.5 20

6SE7024-7TP0 47.0 22

6SE7026-0TP0 59.0 24

6SE7027-2TP0 72.0 26

 = 5 corresponds to MASTERDRIVES Motion Control

= 7 corresponds to MASTERDRIVES Motion Control Performance 2

Frequency

converter, Compact

PLUS AC-AC type

Inverter, Compact

PLUS DC-AC type

Guidelines for Start-Up3
Definitions and Warnings6
Register12
Contents14
1 System Description25
- 1.1 Overview25
- 1.2 System description26
- 1.3 Construction sizes27
- 1.4 Communication28
2 Configuration and Connection Examples29
- 2.1 Compact PLUS type units29
- 2.2 Compact and chassis-type units37
- 2.3 Points to look out for when using certain option boards and CUPM44
- 2.4 Safe stop functions of electrical drive systems in accordance with DIN EN 61800-5-246
3 Instructions for Design of Drives in Conformance with EMC Regulations88
- 3.1 Foreword88
- 3.2 Principles of EMC89
- 3.3 The frequency converter and its electromagnetic compatibility91
  - 3.3.1 The frequency converter as a noise source91
  - 3.3.2 The frequency converter as a noise receiver94
- 3.4 EMC planning95
  - 3.4.1 The zone concept97
  - 3.4.2 Use of filters and coupling elements99
- 3.5 Design of drives in conformance with EMC regulations100
  - 3.5.1 Basic EMC rules100
  - 3.5.2 Examples106
- 3.6 Assignment of SIMOVERT MASTERDRIVES, radio interference suppression filters and line reactors113
- 3.7 Specified standards113
4 Function Blocks and Parameters114
- 4.1 Function blocks114
- 4.2 Connectors and binectors115
- 4.3 Parameters117
- 4.4 Connecting up function blocks (BICO system)121
5 Parameterization123
- 5.1 Parameter menus123
- 5.2 Changeability of parameters127
- 5.3 Parameter input via the PMU128
- 5.4 Parameter input via the OP1S133
- 5.5 Parameter input with DriveMonitor154
6 Parameterizing Steps166
- 6.1 Parameter reset to factory setting168
- 6.2 Detailed parameterization170
- 6.3 Quick parameterization procedures189
7 Functions210
- 7.1 Basic functions210
  - 7.1.1 Time slots210
  - 7.1.2 Processing sequence of the function blocks215
    - 7.1.2.1 Time monitoring216
    - 7.1.2.2 Influencing the time response217
- 7.2 Technology functions219
- 7.3 Converter functions260
- 7.4 Special functions282
  - 7.4.1 Loading firmware282
8 Communication287
- 8.1 Universal Serial lnterface (USS)288
- 8.2 PROFIBUS331
- 8.3 SIMOLINK472
- 8.4 CBC Communications Board499
- 8.5 CBC CANopen communication board559
9 Technology Option F01692
- 9.1 Enabling technology option F01692
- 9.2 Overview of the documentation692
- 9.3 Application areas694
- 9.4 Brief description of the technology functions707
- 9.5 Communication with the technology801
- 9.6 Configuration811
- 9.7 Application examples814
- 9.8 Commissioning the technology842
- 9.9 Faults, warnings, diagnostics868
- 9.10 Hardware and software replacement measures869
- 9.11 Modification history of technology option F01870
- 9.12 References, software products and accessories884
10 Control Word and Status Word887
- 10.1 Description of the control word bits887
- 10.2 Description of the status word bits895
11 Engineering Information901
- 11.1 Clarification of the type of drive, technical data and other border conditions902
- 11.2 Specification of the travel curve903
- 11.3 Calculation of the maximum speed under load and the maximum load torque, selection of the gear904
- 11.4 Selection of the motor912
- 11.5 Selection of converters or inverters917
- 11.6 Selection of the rectifier unit for multi-axis drives919
- 11.7 Selection of the braking units and braking resistors921
- 11.8 Selection of other components922
- 11.9 Calculating example925
- 11.10 Power Extension PIN F02 (from firmware version 2.20 and higher)945
Function Diagrams947
- Basic functions948
- Free blocks1036
- Supplementary boards1087
- Technology option1112
Parameter Lists1158
- General parameter list1160
- Connector list1416
- Binector list1446
- List of function data set parameters1466
- List of binector data set parameters1471
- List of binector and connector parameters1475
Faults and Alarms1488
- Faults1488
- Alarms1500
- Fatal errors (FF)1522
Lists of Stored Motors1523
- Synchronous motors1523
- Torque motors1529
- Asynchronous motors1531
Dimension Drawings1534
Versions1544
