08.2012 Parameterizing Steps
Siemens AG 6SE7087-6QX70 (Version AN)
SIMOVERT MASTERDRIVES Compendium Motion Control 6-17
P071 = ?
Input unit line voltage in V
AC units: RMS value of AC voltage
DC units: DC link voltage
P060 = 5
Select "Drive setting" menu
P095 = ?
Input of motor type
0: No motor connected
1: Synchronous servomotor 1FT6/1FK6
2: Asynchronous servomotor 1PH7(=1PA6)/1PL6/1PH4
3: Synchronous servomotor general
4: Asynchronous servomotor
5: Torque motor 1FW3
P096=?
P095 = 1 2 3 4
P097=?
Input of code number for the connected
1FK6/1FT6 motor (see list attached)
Input of code number for the connected
1PH7(=1PA6)/1PL6/1PH4 motor (see list attached)
P101 = ?
Input of motor rated voltage in V
according to rating plate
P102 = ?P102 = ?
Input of motor rated current in A
according to rating plate
P103 = ?
Input of magnetizing current in A
If this is not known, enter "0" here. The value is then calculated
by the automatic parameterization.
P104 = ?
Input of power factor cos(phi)
according to rating plate
P107 = ?
Input of motor rated frequency in Hz
according to rating plate
P108 = ?
Input of motor rated speed in rpm
according to rating plate
P108 = ?
P099 = ?
5
Input of code number for the connected 1FW3 motor
(see list attached)
