SIMOVERT MASTERDRIVES Compendium Motion Control 7-5
The following assignment applies regarding the parameterization of
time slots in parameters U950 to U953:
Time slot Parameter value
T0 -
T1 -
T2 2
T3 3
T4 4
T5 5
T6 6
T7 7
T8 8
T9 9
T10 10
T20 20
Examples:
1. Function block 350 should be processed in time slot T4:
U953.50 = 4
2. Function block 390 should be processed in time slot T9:
U953.90 = 9
3. Function block 374 should not be processed:
U953.74 = 20
When the units are delivered, time slots are already assigned to the
function blocks. You should adjust these to suit your requirements once
you have determined the interconnection of the function blocks.
Please note that an incorrect processing sequence will lead to
uncontrolled axis movements!
DANGER
