Functions 09.2008
6SE7087-6QX70 (Version AK) Siemens AG
7-74 Compendium Motion Control SIMOVERT MASTERDRIVES
Loading the firmware from a laptop/PC entails the steps listed below.
All other programs using the same PC port (COM1 or COM2) (e.g.
DriveMonitor) must be closed from the outset.
If problems should occur with the loading program bsl.exe under
Windows NT, the program Win BSL.exe is also available after
installation of DriveMonitor (Path: \Siemens\DriveMonitor\
P7vrvisx\SYSTEM\WINBSL).
Before you load the software, save your parameter settings (upread
with OP1S, or upload with DriveMonitor)!
If the position after the decimal point of the firmware changes (e.g.
when upgrading from 1.3x to 1.4x), the module is reset in full. A CUPM
signals status °000 and waits for the power section definition (input of
the converter ID in P070).
The following parameters are read and stored when upload from
DriveMonitor, but not written to the unit when downloaded for safety
reasons:
Parameter number Parameter name
P060 Menu selection
P070 Order No. 6SE70..
P072 Conv.current(s)
P073 Conv.power(s)
P700 IF bus address
P701 IF baudrate
P702 IF no. of PKW
P703 IF no. of PZD
P918 CB bus address
P952 Number of faults
P970 Factory setting
P971 EEPROM accept.
U976 Product number
U977 PIN
Table 7-6 Parameters that cannot be changed on downloading with DriveMontitor
Where necessary, these parameters must be parameterized
separately, for example, via the parameter menu of DriveMonitor; via a
script file, or directly on the converter. The values of the specified
parameters can be viewed by opening the backed-up download file in
DriveMonitor "offline".
