Parameter ID
1st word
Bit No.: 15 12 11 10 0
AK SPM PNU
Parameter index
2nd word
Bit No.: 15 8 7 0
Index High Index Low
Parameter value
Parameter value High (PWE1) 3rd word
Parameter value Low (PWE2) 4th word
AK: Task or reply ID
SPM: Toggle bit for processing of parameter-change reports
PNU: Parameter number
The PKW area is transferred in increasing order, always starting with
the 1st word.
Structure of the
parameter area
(PKW)
NOTE
