09.2008 Communication / PROFIBUS

Siemens AG 6SE7087-6QX70 (Version AK)

SIMOVERT MASTERDRIVES Compendium Motion Control 8.2-7

There are five types of PPO:

♦ Useful data without a parameter area with two words or six words of

process data

♦ or useful data with a parameter area and two, six or ten words of

process data.

PKW PZD

PKE

IND

PWE

PZD1

STW1

ZSW1

PZD2

HSW

HIW

PZD3

PZD4

PZD5

PZD6

PZD7

PZD8

PZD9

PZD10

Word

PPO1

PPO2

PPO3

PPO4

PPO5

PKW:

PZD:

PKE:

IND:

PWE:

Parameter ID value

Process data

Parameter ID

Index

Parameter value

STW:

ZSW:

HSW:

HIW:

Control word 1

Status word 1

Main setpoint

Main actual value

Table 8.2-1 Parameter process data object (PPO types)

Dividing the useful data into parameter identifier values and process data

enables different tasks to be carried out.
