09.2008 Communication / PROFIBUS
Siemens AG 6SE7087-6QX70 (Version AK)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.2-53
♦ Connection of a PROFIBUS slave to an optical single-fiber ring
♦ Cable length between 2 OLPs with plastic fiber-optic cable from 1 m
to 25 m
♦ Maximum circumference of a single-fiber ring: 275 m
♦ Transmission rate of 93.75 kbit/s to 1.5 Mbit/s; can be adjusted by
means of plug-in jumpers (this can be checked through inspection
windows in the connector housing)
♦ OLP single-fiber rings can be integrated in PROFIBUS networks by
means of OLM/Ps
♦ One OLM/P per single-fiber ring is necessary as a coordinator.
OLP / OLM for PROFIBUS Order No.
OLP
Optical link plug for creating optical single-fiber rings with
plastic fiber-optic cables; including 2 HP Simplex
connectors and mounting instructions
6GK1 502-1AA00
OLM/P3
Optical link module for plastic fiber-optic cables, 3-
channel version with signaling contact, including 2 BF
OC connectors
6GK1 502-3AA10
OLM/P4
Optical link module for plastic fiber-optic cables, 4-
channel version with signaling contact, including 4
BFOC-connectors
6GK1 502-4AA10
For more information on ordering and additional descriptions, see the
A&D AS catalog "Industrial Communication" IK 10
(Order No. E86060-K6710-A101-A6).
Functions
Requirements for
use
Ordering data
