Communication / PROFIBUS 09.2008
6SE7087-6QX70 (Version AK) Siemens AG
8.2-120 Compendium Motion Control SIMOVERT MASTERDRIVES
Alarm number Meaning
First
CB/TB
Second
CB
A 088 A 096 Only CBP2
At least one configured cross-traffic encoder is not yet
active or has failed. For details, see CBP2 diagnostic
parameters.
Consequence:
If a encoder is still not active, the relevant setpoints are
set to null as a substitute.
If a cross-traffic encoder fails, transmission of the
setpoints to the basic unit may be interrupted,
depending on the setting in P715. Secondary fault
F082.
Table 8.2-25 Alarm display on the basic unit
The alarm number for the first CB/TB applies to the following
configurations:
♦ Exactly one CBP has been plugged into slots A to G in the electronics
box and no T100/T400 technology board has been plugged in
♦ If two CBPs have been plugged in, the alarm number applies to the
one which has been plugged into the slot with the lower slot letter.
The alarm number for the second CB applies to the following
configurations:
♦ One T100/400 technology board has been plugged in and the CBP in
the electronics box has been plugged into slots A to C.
♦ If two CBPs have been plugged in, the alarm number applies to the
one which has been plugged into the slot with the higher letter.
The alarm A 082 / A 090 can also be displayed on the basic unit the first
time the CBP is started as long as telegrams are not being exchanged
with a DP master, e.g. because the bus cable has not yet been
connected.
Assignment
NOTE
