09.2008 Communication / PROFIBUS
Siemens AG 6SE7087-6QX70 (Version AK)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.2-123
Index number
Meaning 1st CBP 2nd CBP
Reserved .12 (High) .44 (High)
Determined PPO type (8 bits) .13 (Low) .45 (Low)
Reserved .13 (High) .45 (High)
Mirroring "DWORD-Specifier-ref" .14 .46
Mirroring "DWORD-Specifier-act" .15 .47
Counter DPV1:DS_WRITE, positive acknowledgement .16 (Low) .48 (Low)
Reserved .16 (High) .48 (High)
Counter DPV1: DS_WRITE, negative
acknowledgement
.17 (Low) .49 (Low)
Reserved .17 (High) .49 (High)
Counter DPV1:DS_READ, positive acknowledgement .18 (Low) .50 (Low)
Reserved .18 (High) .50 (High)
Counter DPV1:DS_READ, negative acknowledgement .19 (Low) .51 (Low)
Reserved .19 (High) .51 (High)
Counter DP/T: GET DB99, positive acknowledgement .20 (Low) .52 (Low)
Counter DP/T: PUT DB99, positive acknowledgement .20 (High) .52 (High)
Counter DP/T: GET DB100, positive acknowledgement .21 (Low) .53 (Low)
Counter DP/T: PUT DB100, positive acknowledgement .21 (High) .53 (High)
Counter DP/T: GET DB101, positive acknowledgement .22 (Low) .54 (Low)
Counter DP/T: PUT DB101, positive acknowledgement .22 (High) .54 (High)
Counter DP/T-service negative acknowledgement .23 (Low) .55 (Low)
Counter DP/T: application relation, positive
acknowledgement
.23 (High) .55 (High)
Reserved .24 .56
Generating date: day, month .25 .57
Generating date: year .26 .58
Software version .27 .59
Software version .28 .60
Software version: flash EPROM checksum .29 .61
Reserved :
Reserved .32 .64
Table 8.2-27 CBP diagnostics buffer
