Siemens simovert masterdrives Compendium

09.2008 Communication / PROFIBUS
Siemens AG 6SE7087-6QX70 (Version AK)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.2-133
Display
im r732
When
P711 =
21
When
P711 =
22
When
P711 =
23
When
P711 =
24
When
P711 =
25
When
P711 =
26
ii 09
PZD
rights
PZD
rights
PKE’ PKE’ PZD1’ PZD1’
ii 10 xxx xxx IND’’ IND’’ PZD2’ PZD2’
ii 11 xxx xxx PWE1’ PWE1’ PZD3’ PZD3’
ii 12 xxx xxx PWE2’ PWE2’ PZD4’ PZD4’
ii 13 xxx xxx PWE3’ PWE3’ PZD5’ PZD5’
ii 14 xxx xxx PWE4’ PWE4’ PZD6’ PZD6’
ii 15 xxx xxx PWE5’ PWE5’ PZD7’ PZD7’
ii 16 xxx xxx PWE6’ PWE6’ PZD8’ PZD8’
ii 17 xxx xxx PWE7’ PWE7’ PZD9’ PZD9’
ii 18 xxx xxx PWE8’ PWE8’ PZD10’ PZD10’
ii 19 xxx xxx PWE9’ PWE9’ PZD11’ PZD11’
ii 20 xxx xxx PWE10’ PWE10’ PZD12’ PZD12’
ii 21 xxx xxx PWE11’ PWE11’ PZD13’ PZD13’
ii 22 xxx xxx PWE12’ PWE12’ PZD14’ PZD14’
ii 23 xxx xxx PWE13’ PWE13’ PZD15’ PZD15’
ii 24 xxx xxx PWE14’ PWE14’ PZD16’ PZD16’
Table 8.2-30 Telegram contents in parameter r732i09 which can be read out
(communication with DriveMonitor)
By means of CB parameter 3, i.e. P713 / P698, a hex monitor can be
activated with which addresses of the dual-port RAM can be read out on
the CBP.
Parameter P713 / P698 is to be reserved exclusively for suitably
trained start-up personnel.
In order to use the hex monitor to best effect, appropriate detailed
knowledge of the structure of the dual-port RAM is necessary.
In P713 / P698, only the offset address (decimal) is entered.
If CB Parameter 3 is set to a value other than "0", 12 bytes are cyclically
entered in diagnostic parameter r732 from r732.9 onwards. This is done
from the absolute address set in CB parameter 3 (decimal) onwards.
CB Parameter 3 has the highest priority and disables entries by CB
parameter 1.
A Class II master (normally a PG programming unit) can be used for
start-up and diagnosis. During start-up/testing, the Class II master
assumes the function of the Class I master for the selected station. The
exchange of useful data with the slave, however, is not cyclical.
Telegram contents
(communication
with DriveMonitor)
CB parameter 3
(DPRAM monitor)
DANGER
Diagnosis with
PROFIBUS Class II
Master
