Siemens simovert masterdrives Compendium

09.2008 Communication / PROFIBUS
Siemens AG 6SE7087-6QX70 (Version AK)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.2-135
Fault S7 protocol (r732.22), fault numbers < 150 correspond to PKW fault
numbers:
No. Cause Remedy (e.g. in ProTool)
No. 0 .. 199: S7 task has been changed into a parameter task. Fault detection in the basic board
or technology board. Additional info in r732.23, r732.24: parameter number, index word.
0 There is no parameter number Check data block number
1 Parameter value cannot be altered -
2 Top or bottom limit exceeded -
3 There is no subindex Check data block offset
4 Access to single value with array identifier Set data block offset = 0
5
Access to word with double word task or vice
versa
Use correct type of data
(e.g. INT for word, DINT for double word)
6 Setting not allowed (can only be reset) -
7 Description element cannot be altered (should not occur here)
11 No parameter change rights -
12 Keyword missing -
15 There is no text array -
17
Task cannot be executed due to operating
status
-
101 Parameter number deactivated at the moment -
102 Channel width too small (should not occur here)
103 PKW number incorrect (should not occur here)
104 Parameter value not permissible -
105 Access to array parameter with single identifier Set data block offset > 0
106 Task not implemented -
No. 200-209: S7 task is formally defective. Error detection in the COM BOARD.
Additional info in r732.23, r732.24: data block number, data block offset
200 Error in variables address (no addiional info) Permissible: range of "Data block"
201 Data block number not permissible Permissible: 1...31999
202 Data block offset not permissible
Permissible:
0...116, 10001...10116, 20000...20010
203
Non-permissible "Type" during access to
parameter value
Permissible: CHAR. BYTE, INT, WORD, DINT,
DWORD, REAL
204
Non-permissible "Number of elements" during
access to parameter value
Permissible: effective 2 or 4 byte
205 Non-permissible "Type" during access to text Permissible: CHAR, BYTE
206
Non-permissible "Type" during access to
description
Permissible: CHAR. BYTE, INT, WORD, DINT,
DWORD, REAL
207
Non-permissible odd "Number of elements" in
the case of type CHAR or BYTE
Correct the "Number of elements"
208 Non-permissible change of text/description -
209
Inconsistency in the write task: "Type" and
"Number of elements" does not match "Type of
data" and "Length of data"
(Defective communications partner)
