SIMOVERT MASTERDRIVES Compendium Motion Control 8.4-19
Reply ID Meaning
0 No reply
1
Transfer parameter value in the case of non-indexed
parameters (word)
2
Transfer parameter value in the case of non-indexed
parameters (double word)
3 Transfer descriptive element
1
4
Transfer parameter value (array, word) in the case of indexed
parameters
2
5
Transfer parameter value (array, double word) in the case of
indexed parameters
2
6 Transfer number of array elements
7 Task cannot be executed (with error number)
8 No operator change rights for the PKW interface
9 Parameter change report (word) (not with the CBC)
10 Parameter change report (double word) (not with the CBC)
11 Parameter change report (array, word)
2
(not with the CBC)
12
Parameter change report (array, double word)
2
(not with the
CBC)
13 Reserved
14 Reserved
15 Transfer text (not with the CBC)
1
The required element of the parameter description is specified in IND (2nd word)
2
The required element of the indexed parameter is specified in IND (2nd word)
Table 8.4-6 Reply ID (converter -> master)
Source for the ON/OFF command (control word 1, bit 0): P554 (=22A
Hex)
Change parameter value (array, word) and store in the EEPROM.
1st word
Parameter ID (PKE)
Bit No.: 15 12 11 10 0
AK SPM PNU
Byte 1 Byte 0
Binary value 1 1 0 0 0 0 1 0 0 0 1 0 1 0 1 0
HEX value C 2 2 A
Bits 12 to 15:
Bits 0 to 11:
Value = 12 (= "C" Hex); change parameter value (array, word)
and store in the EEPROM
Value = 554 (= "22A" Hex); parameter number without a set
parameter change report bit
Example of
parameter identifier
