03.2010 Communication / CBC
Siemens AG 6SE7087-6QX70 (Version AL)
SIMOVERT MASTERDRIVES Compendium Motion Control 8.4-53
LED Status Diagnostic information
Red Flashing CBC is waiting for completion
Yellow Continuously lit of parameterization by the
Green Off converter / inverter
Table 8.4-12 Fault display during parameterization
LED Status Diagnostic information
Red Flashing No net-data traffic via the CAN bus,
Yellow Flashing e.g. bus connector pulled out, EMC fault,
Green Off
interchanged connection, nodes are not being
supplied with net data via the CAN bus
Table 8.4-13 Fault display during operation
During normal operation, all three LEDs light up synchronously and for
the same length of time (flashing)!
The stationary status of an LED (on or off) indicates an unusual
operating status (parameterization phase or fault)!
NOTE
