Technology Option F01 08.2012

6SE7087-6QX70 (Version AN) Siemens AG

9-66 Compendium Motion Control SIMOVERT MASTERDRIVES

The diagram below shows an overview of the parameter settings.

Fig. 9-26

The following example shows the referencing sequence.

J_FWD

Mode

Mode=2

Rough pulse

Drive speed

Ramp

MD41

Ramp

MD42

Rotor zero

MD7: Home position

approach velocity

MD6:

Home position

reducing velocity

Axis referenced

checkback signal

Fig. 9-27

Parameter settings

Example

Guidelines for Start-Up3
Definitions and Warnings6
Register12
Contents14
