05.2006 Control Word and Status Word
Siemens AG 6SE7087-6QX70 (Version AG)
SIMOVERT MASTERDRIVES Compendium Motion Control 10-5
Bit 10: Control from the PLC command (H "control from the PLC")
HIGH signal; the process data PZD (control word, setpoints) are only
evaluated if the command has been accepted; this data is sent via the
SST1/2 interface of the CUPM, the CB/TB interface (option) and the
SCB2 interface (option). In the case of Compact Plus, the SST1/2 inter-
face is on the basic board; the TB and SCB2 interfaces do not exist.
If several interfaces are used, only the process data of the interfaces
are evaluated, which send an H signal.
For an L signal, the last values are received in the appropriate dual
port RAM of the interface.
An H signal appears in the visualization parameter r550 "control word
1", if one of the interfaces sends an H signal!
Bit 11: Clockwise rotating field command (H "clockwise rotating field")
HIGH signal
The setpoint is influenced in conjunction with bit 12 "counter-
clockwise rotating field".
Refer to the function diagram "Setpoint processing (Part 1)" (310)
Bit 12: Counter-clockwise rotating field command (H "counter-clockwise rotating field")
HIGH signal
The setpoint is influenced in conjunction with bit 11 "clockwise-
rotating field".
Refer to the function diagram "Setpoint processing (Part 1)" (310)
The counter-clockwise rotating field and the clockwise rotating
field command have no influence on supplementary setpoint 2, which
is added after the ramp-function generator (RFG)!
Bit 13: Command to raise the motorized potentiometer (H "raise motorized
potentiometer")
HIGH signal
The motorized potentiometer in the setpoint channel is driven in
conjunction with bit 14 "motorized potentiometer, lower".
Refer to the function diagram "Motorized potentiometer" (300)
Bit 14: Command to lower the motorized potentiometer (H "lower motorized
potentiometer")
HIGH signal
The motorized potentiometer in the setpoint channel is driven in
conjunction with bit 13 "raisemotorized potentiometer".
Refer to the function diagram "Motorized potentiometer" (300)
Condition
Result
NOTE
Condition
Result
Condition
Result
NOTE
Condition
Result
Condition
Result
