Commissioning
4.10 Safety Integrated commissioning
Commissioning with Startdrive
222 Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
Making basic settings
4.10.2.1
Starting the safety commissioning
Requirement
For safety reasons, you can only set the safety-relevant parameters of the 1st channel offline
for Startdrive. To set the safety-relevant parameters of the 2nd channel, the drive must be
online. The settings are protected by a password.
Startdrive is not online.
Startdrive is online. The processing mode is not activated yet.
Startdrive is online. The processing mode is active. In addition to the safety mark-
ing, a "pin"
is displayed in the secondary navigation.
Activating safety settings
1. Click the "Go online" icon.
2. Click the
icon in the toolbar of the parameterization editor.
The dialog for the password input opens.
3. Enter the password.
You only have to enter a new password at the first start to replace the default password.
4. Click "OK" to accept the settings.
The safety commissioning is activated.
