Siemens SINAMICS S120 - Comparing Parameter Settings

Fundamentals
3.4 Comparing parameter settings
Commissioning with Startdrive
70 Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
3.4
Comparing parameter settings
The current parameter values of a drive object can be compared with another parameter set
using the comparison function in the parameter view. The following comparisons are
possible:
● Offline - Factory setting
● Online - Offline
● Online - Factory setting
Comparing parameters
To compare the parameters of the drive object with another parameter set, proceed as
follows:
1. Open the parameter view for the device whose parameters you want to compare.
2. Click the black arrow icon of the
"Compare current parameters of this drive object
with another data set" button.
A selection list containing the comparison options opens:
– Offline - Factory setting (default setting in offline mode)
– Online - Offline (default setting in online mode)
– Online - Factory setting
3. Select a comparison option.
The selected comparison option is executed as follows:
– The "Comparison" column is displayed.
– The comparison result of the selected comparison option is displayed by icons in the
"Comparison" column.
Quick compare depends on parameterization mode:
1. Click the scales icon on the button.
Result
:
– Offline mode: By default, the parameters are compared with the factory settings.
– Online mode: By default, the parameters are compared with the offline settings.
