3.4 Comparing parameter settings
Commissioning with Startdrive
Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
71
Icons in the "Comparison" column
Icon
Meaning
The comparison values are equal and error-free.
Offline - Factory setting:
The comparison values are different and error-free.
Online - Offline:
The comparison values are different and error-free.
Online - Factory setting:
The comparison values are different and error-free.
The value of at least one subordinate parameter index is different from the factory
setting.
The value of at least one subordinate parameter index is different from the offline
value.
At least one of the two comparison values has a technological or syntax error.
The comparison cannot be performed. At least one of the two comparison values
is not available (e.g. snapshot).
