Commissioning
4.10 Safety Integrated commissioning
Commissioning with Startdrive
252 Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
Test of an external brake
The following figure shows the communication via SIC and SCC during the test of an
external brake:
