Diagnostics
5.3 Diagnostics via Startdrive
Commissioning with Startdrive
Commissioning Manual, 11/2017, 6SL3097-4AA10-0BP1
335
Third error case: DRIVE-CLiQ connection inserted on the interface of an incorrect drive
object
If more complex topology errors are present, correct them step-by-step and note the
following changes in the device view. As a result of the error combination, not all errors can
be directly analyzed and displayed.
1. Check the interface marked red on the first drive object, for example the Single Motor
Module.
The tooltip displays that a connection, which is not configured, is inserted at interface
X201.
2. Disconnect the connection from interface X201. The interface is displayed as being error-
free after the device view has been updated. In addition, errors are displayed on the
Double Motor Module and on the Sensor Module.
vice view is not automatically updated after changing the wiring, simply change
briefly to the network view.
3. Check the red interfaces on the Motor Module and on the Sensor Module.
The tooltip displays that the Sensor Module is not inserted on the Double Motor Module.
4. Insert the connection and acknowledge the pending messages.
The topology is displayed as being error-free.
