4.3 Motor Module with external air cooling
Booksize power units
368 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
Table 4-24 Technical data for Single Motor Modules booksize (45 to 200 A)
External air cooling 6SL3121– 1TE24-
5AAx
1TE26-
0AAx
1TE28-
5AAx
1TE31-
3AAx
1TE32-
0AAx
Rated current A 45 60 85 132 200
Voltage
Infeed:
DC link voltage
Electronics power supply
V
DC
V
DC
510 – 720
24 (20.4 - 28.8)
Output voltage V
ACrms
0 - 0.717 x DC link voltage
Overvoltage tripping
Undervoltage tripping
V
DC
V
DC
820 ± 2 %
380 ± 2 %
Electronics current consumption at 24 V A
DC
1.2 1.2 1.5 1.5 1.5
Total power loss
(including electronic losses)
1)
W 458.8 618.8 786 1286 2086
Rated output current (l
n
) A
ACrms
45 60 85 132 200
Base load current (I
geund
) A 38 51 68 105 141
Intermittent duty current (l
s6
) 40 % A
ACrms
60 80 110 150 230
Peak current (l
max
) A
ACrms
85 113 141 210 282
DC link busbar current carrying
capacity
A
DC
100 100 200 200 200
24 V busbar current carrying capacity A
DC
20 20 20 20 20
Rated power
(with DC link voltage of 600 V
DC
and
clock cycle frequency of 4 kHz)
kW 24 32 46 71 107
Max. pulse frequency without derating kHz 4 4 4 4 4
Max. pulse frequency with derating kHz 16 16 16 16 16
Max. ambient temperature without
derating
°C 40 40 40 40 40
Max. ambient temperature with
derating
°C 55 55 55 55 55
DC link capacitance μF 1175 1410 1880 2820 3995
Sound pressure level dB(A) < 65 < 65 < 60 < 73 < 73
Cooling air requirement m
3
/h 112 112 160 520 520
Weight kg 13.2 13.3 17.2 27.1 28
Table 4-25 Technical data for Double Motor Modules Booksize (3 to 18 A)
External air cooling 6SL3121- 2TE13-0AAx 2TE15-0AAx 2TE21-0AAx 2TE21-8AAx
Rated current A 2x3 2x5 2x9 2x18
Voltage
Infeed:
DC link voltage
Electronics power supply
V
DC
V
DC
510 – 720
24 (20.4 - 28.8)
