Accessories
8.1 Shield connecting plates
Booksize power units
450 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
Figure 8-7 Dimension drawing of shield terminal plate on a 100 mm component (Line Module or Motor Module) with
external air cooling
Note
The shield connecting plate is part of the scope of supply of a 100 mm Line Module.
Recommended shielding connection clamps: Weidmüller, Order No. KLBÜ CO4
Weidmüller: http://www.weidmueller.com
