Page #1019 background image
3.3 Definition and functions for start softkeys
3.3.1 Defining the start softkey
Dialog-independent softkey
Start softkeys are dialog-independent softkeys which are not called from a dialog, but which
have been configured before the first new dialog. In order to access the start dialog or a start
softkey menu, the start softkey must be defined.
Programming
The definition block for a start softkey is structured as follows:
//S(Start) ; Start identifier of start softkey
HS1=(...) ; Define the start softkey: Horizontal SK 1
PRESS(HS1) ; Method
LM... ; LM or LS function
END_PRESS ; End of method
//END ; End identifier of start softkey
Permissible positions for start softkeys
The following positions for "Run MyScreens" start softkeys are permissible in the operating
areas:
Operating area Position
Machine HSK6
Parameter HSK7
Program HSK6 and HSK15
Measuring cycles: HSK13 and HSK14
Program manager HSK2-8 and HSK12-16, if not assigned to drives.
Diagnostics HSK7
Startup HSK7
Start softkeys are configured in special files. The names of these files are stated in the
easyscreen.ini file. They usually have a name which is specific to an operating area (e.g.
startup.com for the startup area). The machine operating area represents an exception. There
are several mode-specific files in the machine operating area (ma_jog.com, ma_auto.com).
The softkey menu with the start softkeys is called "Start". Existing configurations for start
softkeys can still be used. The function whereby start softkeys are merged with the softkeys
for the respective HMI application (operating area) in the start softkey menu is not supported.
Fundamentals
3.3 Definition and functions for start softkeys
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 33
